Product Discontinued
Spire series
**DISCONTINUED** Broan® Elite 36-Inch Under-Cabinet Range Hood w/ Light, Stainless Steel
Model:
SPE136SS
Features
![1-Person Installation in Half the Time](https://www.broan-nutone.com/getmedia/21e62f54-8d30-477b-a3b8-6fa6dfe913fe/EZ1-badge.jpg?width=656&height=608&ext=.jpg)
1-Person Installation in Half the Time
![HVI Certified](https://www.broan-nutone.com/getmedia/e07fbc5a-3ec8-4b01-ba12-e340f82da63d/HVILogo.PNG?width=237&height=183&ext=.png)
HVI Certified
![UL Listed](https://www.broan-nutone.com/getmedia/6201b0f3-0fd6-4b56-9b0e-6f1367e4f203/ULLogo.PNG?width=944&height=944&ext=.png)
UL Listed
- Model replaced EPLEC136SS
- The Captur™ system's advanced blower design features a centric inlet to remove smoke and odor faster. Three-speed blower control exhausts at a powerful 600 CFM
- Forward placement and smooth-flow blower wheel design ensure quiet, <0.3 Sones operation at normal speed
- Tap-touch, 3-speed capacitive control features a smooth, easy-to-clean surface
- Dishwasher-safe, hybrid baffle filters provide ultra-efficient grease removal with superior air flow. The filter clean reminder ensures they will always maintain a high level of capture
- EZ1 brackets enable single-person installation in less than half the time of traditional methods
- ADA compliant, remote operation is possible using a standard UL approved wall switch.
- Bright, two-level ENERGY STAR® LED modules – supported by a 3-year warranty – illuminate evenly and are tested in cooking environments to ensure long life without dimming. Color Temperature 3000 K
- Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
- Range hood is installed as hardwired or with an optional power cord kit (SHCK44; sold separately)
- Specs
- Downloads
Filter Type | Hybrid Baffle |
---|---|
Heat Sentry™ | No |
HVI Certified | Yes |
Lighting Type | LED |
Sound Level (Sones) | 0.3 |
UL Listed | Yes |
ADA Compliance | Yes |
Damper Included | No |
ENERGY STAR® certified | No |
Light Bulb Wattage | 4.5 |
Light Bulbs Included | Yes |
Light Levels | 2 |
Material | Steel |
Nightlight Or Nighlight Setting | No |
Ductless Recirculation Capable | Yes |
Ductless Filter Or Kit Included | No |
Remote Operation Capable | No |
Speed Levels | 3 |
Switch Control Type | Capacitive Touch |
Rated Voltage | 120 |
Boost Mode | No |
Country of Origin | Mexico |
Color Finish |
|
Rated Amps | 1.9 |
Product Depth | 19.25 |
Product Height | 9" |
Product Width | 36" |
Built-In Timer | No |
Capture Efficiency | 98.5 |
CFM | 600 |
Diameter | 7" Round |
Vent Type | Convertible Built-In |
Duct Direction | Horizontal/Vertical |
Bulb (Recommended Type) | Integrated LED Module |
Light Color Temp | 3000 |
Manufacturer Warranty | 1 Year, 3 Year LED module |
Wattage | 228 |
