Broan® Elite EW58 Series Chimney Range Hood

Broan® 30-Inch Convertible Canopy Wall-Mount Range Hood w/ Heat Sentry®, 500 CFM, Stainless Steel

30" Stainless Steel Traditional Canopy Chimney Hood with Internal 500 CFM Blower. This timeless European design has LED indicator push button controls with LED indicators, 3 level halogen lighting and Heat Sentry® sensing which automatically turns blower on high speed when excessive heat is detected.


Color Finish


Product Width


Model:

EW5830SS

Features

  • Powerful 500 CFM internal blower
  • Bright dual halogen lighting (bulbs included); 3 intensities
  • 3-speed electronic push control with blue speed selection indicator
  • Control features Delay-off and Filter clean reminder
  • Optional remote control operation (sold separately)
  • Quick-release aluminum filters
  • Designed to work with Broan Automatic Make-up Air Dampers
  • Heat Sentry® detects excessive heat and adjusts blower to High speed automatically
  • Telescopic flue accommodates ceiling heights 8' to 9'; optional flue extension for either ducted or non-ducted 9' to 10' ceilings can be purchased separately
  • This hood can be installed non-ducted with the use of the Non-Duct Kit (sold separately)
  • Specs
  • Downloads

print

UL Listed Yes
Accommodates Ceiling Height
Light Bulb Quantity 2
Filter Type Aluminum
Damper Included Yes
Flue Accommodates ceilings up to xx ft
ADA Compliance No
HVI Certified Yes
Non-Ducted Filter Or Kit Included No
Speed Levels 3
Switch Control Type Push Button
Built-In Timer Yes
Filter (Number Of) 1
Product Width 30"
Vent Type Convertible with Kit
Sones 10.5
Light Bulbs Included Yes
Minimum Height Above Cook Top
Color Finish
Heat Sentry™ Temperature Sensor No
Material
Delay Shut Off No
Manufacturer Warranty 1 Year
Control Feature Filter Reminder No
Digital Clock No
Boost Mode No
Lighting Type Halogen
Product Depth 19.75
Light Bulb Wattage 6.5
CFM Airflow Max 0
CFM Airflow Normal 0
Sones Max 0
CFM 500
Light Color Temp
Diameter 6" Round
Rated Amps 3.05
product.productenergystarqualified No
Nightlight Or Nighlight Setting No
Non-Ducted Recirculation Capable Yes
Mounting Type
Wattage 366
Capture Efficiency
Light Levels 3
Rated Voltage 120
Duct Connector Size 6" Round
Remote Operation Capable No
Bulb (Recommended Type) MR16 / GU10
Height 29.5
Duct Direction Vertical
Heat Sentry™ No
