Product Discontinued

Broan® Elite E64E Under-Cabinet Range Hood Shell

**DISCONTINUED** Broan® Elite 30" Pro-Style Under-Cabinet Range Hood Shell w/ External Blower & Light, Stainless Steel

Model:

E64E30SS

Order Replacement Parts

Features

  • 10" under-cabinet design
  • Brushed stainless steel finish
  • 1290 Max Blower CFM internal blower is included on model (E6448TSS)
  • Dedicated models (E64E30SS, E64E36SS, E64E42SS, E64E48SS) for use with external blower options—choice of eight, from 280–1500 CFM. (Blowers sold separately.)
  • Bright halogen lighting; Two 50-watt bulbs, sold separately
  • Pro-style, dishwasher-safe baffle filters with removable grease drip rail
  • Variable speed control remembers last setting—blue power-on indicator light: Heat Sentry® detects excessive heat and adjusts blower speed automatically
  • Designed to work with Broan automatic make-up air dampers
  • Designed to duct out of the hood shell in either horizontal or vertical direction with internal blowers. External blowers duct vertically
  • Non-duct kit option available

External Blower Options - Must Select One

1620 Max External Blower CFM, for use with Select Broan® Range Hoods

1620 Max External Blower CFM, for use with Select Broan® Range Hoods

Model:

336

View
**DISCONTINUED** 1280 Max External Blower CFM, for use with Select Broan® Range Hoods

**DISCONTINUED** 1280 Max External Blower CFM, for use with Select Broan® Range Hoods

Model:

335

View
880 Max External Blower CFM for use with Select Broan® Range Hoods

880 Max External Blower CFM for use with Select Broan® Range Hoods

Model:

332H

View
**DISCONTINUED** 660 Max External Blower CFM for use with Select Broan® Range Hoods

**DISCONTINUED** 660 Max External Blower CFM for use with Select Broan® Range Hoods

Model:

331H

View
**DISCONTINUED** 1540 Max In-Line Blower CFM for use with Broan® Range Hoods

**DISCONTINUED** 1540 Max In-Line Blower CFM for use with Broan® Range Hoods

Model:

HLB11

View
**DISCONTINUED** 890 Max In-Line Blower CFM for use with Broan® Range Hoods

**DISCONTINUED** 890 Max In-Line Blower CFM for use with Broan® Range Hoods

Model:

HLB9

View
**DISCONTINUED** 670 Max In-Line Blower CFM for use with Broan® Range Hoods

**DISCONTINUED** 670 Max In-Line Blower CFM for use with Broan® Range Hoods

Model:

HLB6

View
320 Max In-Line Blower CFM for use with Broan® Range Hoods

320 Max In-Line Blower CFM for use with Broan® Range Hoods

Model:

HLB3

View
  • Specs
  • Downloads

print

Filter Type Stainless Steel Baffle
Heat Sentry™ No
HVI Certified No
Lighting Type Halogen
Sound Level (Sones) 0
UL Listed Yes
ADA Compliance No
Damper Included No
ENERGY STAR® certified No
Light Bulbs Included No
Light Levels 2
Nightlight Or Nighlight Setting No
Ductless Recirculation Capable Yes
Ductless Filter Or Kit Included No
Remote Operation Capable No
Speed Levels Variable
Rated Voltage 120
Boost Mode No
Color Finish
  • Stainless Steel
Rated Amps 5.5
Product Height 10"
Product Width 30"
Built-In Timer No
CFM 1290 Max
Duct Direction Vertical
Bulb (Recommended Type) MR16 or PAR16
Manufacturer Warranty 1 Year
Wattage 650
Specification Sheet
Installation Guide
