Product Discontinued
Broan® BW50 Series Chimney Range Hood
DISCONTINUED-Broan® 36-Inch Convertible European Style Wall-Mounted Chimney Range Hood, 350 CFM, Stainless Steel
Features
- Three-speed pushbutton control and integrated dual light assembly
- Dual 40-watt incandescent lamp included (Type B10, 120V, 40W max. candelabra)
- Requires separate purchase of a non-ducted kit for indoor exhaust recirculation
- Ducted/non-ducted telescopic flue accommodates ceiling heights from 8 to 9 feet. Flue extension for higher ceilings is also available (Optional flue extension for 10' ceilings – extension over 10' have up to a 14-week order time)
- Non-ducted flue extensions available in stainless steel only (includes non-ducted filter)
- Install hood so that the bottom of the unit is 30 to 36 inches above the cooking surface. Mounting height is affected by ceiling height
- For use with electric cooktops and gas ranges to 45,000 BTUs
- Specs
- Downloads
Filter Type | Aluminum Mesh |
---|---|
Heat Sentry™ | No |
HVI Certified | Yes |
Lighting Type | Incandescent |
Sound Level (Sones) | 9 |
UL Listed | Yes |
ADA Compliance | No |
Damper Included | Yes |
ENERGY STAR® certified | No |
Light Bulbs Included | Yes |
Light Levels | 1 |
Nightlight Or Nighlight Setting | No |
Ductless Recirculation Capable | Yes |
Ductless Filter Or Kit Included | No |
Remote Operation Capable | No |
Switch Control Type | Push Button |
Rated Voltage | 120 |
Boost Mode | No |
Color Finish |
|
Rated Amps | 2.6 |
Product Height | 25.5 |
Product Width | 36" |
Built-In Timer | No |
CFM | 350 |
Diameter | 6" Round |
Duct Direction | Vertical |
Bulb (Recommended Type) | B10 |
Manufacturer Warranty | 1 Year |
Wattage | 396 |
