Broan® Custom 29-Inch Insert Range Hood Kit, Black

The Broan 30 in. Range Hood Custom Insert Kit features rotary dial controls for easy use. The kit has dual centrifugal blowers to help pull smoke and cooking odors from the air. The 24 in. fluorescent tube lighting (bulb not included) helps illuminate your work space. The kit is made of fire retardant metal and is UL listed for safety. Requires Model 103123 Rough-in Kit for complete installation.


Model:

103023

Features

  • Vertically ducted range hood offers high-performance ventilation
  • Rotary dial fan control and rocker light switch for easy use
  • 360 CFM blower helps pull smoke and cooking odors from the air
  • Optional (Sold Seperately), Optional (Sold Separately), Optional (Sold Separately), Optional (Sold Separately)
  • Aluminum grease filter is removable and washable for easy maintenance
  • 24 in. fluorescent tube lighting (bulbs not included) helps illuminate your work space
  • Fire retardant construction for safety
  • 1 year limited warranty
  • UL Listed and HVI-2100 Certified for your safety and protection
  • Requires model 103123 rough-in kit (not included)
  • Specs
  • Downloads

print

Filter Type MicroFoam
Heat Sentry™ No
HVI Certified Yes
Lighting Type Fluorescent
UL Listed Yes
ADA Compliance No
Damper Included No
ENERGY STAR® Certified No
Light Bulbs Included No
Light Levels 1
Nightlight Or Nighlight Setting No
Ductless Recirculation Capable No
Ductless Filter Or Kit Included No
Remote Operation Capable No
Speed Levels Variable
Switch Control Type Rotary
Rated Voltage 120
Boost Mode No
Color Finish
Rated Amps 3.7
Product Height 14
Product Width 29"
Built-In Timer No
CFM 300
Vent Type Ducted Only
Duct Direction Horizontal/Vertical
Bulb (Recommended Type) F20T12 Fluorescent
Manufacturer Warranty 1 Year
Wattage 444
