High-Capacity Ceiling Mount Fans
High-Capacity, Light Commercial 230 CFM Ceiling Mount Ventilation Fan, 1.3 Sones ENERGY STAR® certified
Broan® High-Capacity, Light Commercial ENERGY STAR® certified fans are an exceptionally quiet solution to continuous ventilation. With their heavy-duty motors, high capacity fans are an ideal solution for conference rooms, public restrooms and other areas in commercial buildings that require ongoing ventilation. Low-vibration and lo-profile, they work quietly without getting noticed. 8-way adjustable mounting brackets are included for easy ceiling-mount installation. These solutions can be used to comply with ASHRAE 90.1 (2019), IECC-C (2021), and IMC (2021) and are both HVI and AMCA air and sound tested.
Model:
L200E
Product Data:
Features
ENERGY STAR certified
- 230 CFM, 1.3 sones ceiling mount commercial ventilation fan
- Includes 8-way adjustable mounting brackets for easy ceiling-mount installation
- Duct Horizontally or vertically
- Standard 8" round ducting for all ENERGY STAR® certified models
- ENERGY STAR® certified
- AMCA and HVI air and sound tested
- Can be used to comply with ASHRAE 90.1 (2019), IECC-C (2021), and IMC (2021)
- Model 80L Variable speed control adjusts blower speed and sound level (available separately)
- Metal upgrade grille cover available (MG1)
- Radiation Damper available to prevent the spread of fire (Model RD1 sold separately)
- cULus Listed for safety and protection
Radiation Damper Compatible with this Model
| CFM | 230 |
|---|---|
| Color Finish |
|
| Duct Size | 8 |
| ENERGY STAR® certified | Yes |
| Grille Length | 14" |
| Grille Width | 14" |
| Housing Dimensions | 12.25” x 12.25” x 11.75” |
| Sound Level (Sones) | 1.3 |
| Sound Level (Sones) | 1.3 |
| UL Listed | Yes |
| Grille Finish | White |
| Humidity Sensing | No |
| Motion Sensing | No |
| Motor Engineered For Continuous Operation | Yes |
| Night Light | No |
| Radiation Damper Available | Yes |
| Room Side Installation | No |
| UL Listed for use over bathtubs or showers when connected to a GFCI circuit | No |
| Rated Amps | 0.5 |
| Voltage | 120 |
| Can Be Used To Comply With Title 24 | No |
| Manufacturer Warranty | 1 Year |
| High Efficiency Luminaire | No |
