Broan® Elite Alta 4 Series Under-Cabinet Range Hood
Broan® Elite 30-Inch Convertible Under-Cabinet Range Hood, Stainless Steel
The sculpted lines of Alta™ bring an exciting, new choice to typical range hood shapes. Infrared controls, perimeter aspiration and LED lighting allow you to imagine new design possibilities while you experience the ultimate in capture efficiency. Equipped with the exclusive Broan Captur™ system, which combines advanced blower design with new filter technology, this 650 MAX Blower CFM-rated hood provides 98.5% removal of smoke and odor to protect your home and family from airborne pollutants caused from cooking.
Color Finish
Model:
ALT430SS
Features
1-Person Installation in Half the Time
HVI Certified
UL Listed
- Model replaced EQLD130SS
- The Captur™ system's advanced blower design features a forward positioned centric inlet to remove smoke and odor faster. Three-speed control operates powerful 650 MAX Blower CFM
- Smooth-flow blower wheel design and high flow filters ensure quiet, less than 0.3 sones operation at normal speed
- Three-speed, whisper touch infrared control is a pleasure to use and admire. Delay off feature runs the blower for 10 minutes after cooking to clear the air
- Broan Heat Sentry® detects excessive heat and adjusts the blower speed to prolong the life of the product and provide proper ventilation
- Dishwasher-safe, open-mesh filters enhance grease removal behind a peripheral panel that increases capture of cooking effluents. The filter clean reminder ensures they will always maintain a high level of capture
- EZ1 brackets make it easy for single person installation in less than half the time of traditional methods
- Bright, three-level LED modules – supported by a 3-year warranty – illuminate evenly and are tested in cooking environments to ensure long life without dimming. Color Temperature 3000 K
- Can be installed for ADA Compliance with the purchase of a wall switch (not included) and Broan-NuTone model HAWRK3 Low Voltage Wiring Kit for ADA Application (purchase separately)
- Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
- Range hood is installed as hardwired or with an optional power cord kit (HCK44; sold separately)
- Specs
- Downloads
- Videos
| Filter Type | Peripheral |
|---|---|
| Heat Sentry™ | Yes |
| HVI Certified | Yes |
| Lighting Type | LED |
| Sound Level (Sones) | 0.3 |
| UL Listed | Yes |
| ADA Compliance | Yes |
| Damper Included | No |
| ENERGY STAR® certified | No |
| Light Bulb Wattage | 4.5 |
| Light Bulbs Included | Yes |
| Light Levels | 3 |
| Material | Steel |
| Nightlight Or Nighlight Setting | No |
| Ductless Recirculation Capable | Yes |
| Ductless Filter Or Kit Included | No |
| Remote Operation Capable | No |
| Speed Levels | 3 |
| Switch Control Type | Infrared |
| Rated Voltage | 120 |
| Boost Mode | No |
| Country of Origin | Mexico |
| Color Finish |
|
| Rated Amps | 1.9 |
| Product Depth | 22 |
| Product Height | 5" |
| Product Width | 30" |
| Built-In Timer | No |
| Capture Efficiency | 98.5 |
| CFM | 650 Max |
| Diameter | 7" Round |
| Vent Type | Convertible Built-In |
| Duct Direction | Horizontal/Vertical |
| Bulb (Recommended Type) | Integrated LED Module |
| Light Color Temp | 3000 |
| Manufacturer Warranty | 1 Year, 3 Year LED module |
| Wattage | 228 |
